Now, many people may discard or replace the conveyor belt in Shandong because of a little damage, which greatly increases the cost consumption of the conveyor belt. In fact, sometimes we can reuse it through appropriate repair, but we should emphasize that if the damage is too large, it should be replaced in time, so we should pay attention to this point, The following small series will introduce to you how to repair if the conveyor belt is partially damaged.

由于使用條件惡劣，輸送帶很可能受到一些損傷，為不使損傷擴大，以限度地滿足使用，應對輸送帶的有些損傷進行修補。

Due to poor service conditions, the conveyor belt is likely to suffer some damage. In order not to expand the damage and meet the use to the greatest extent, some damage of the conveyor belt should be repaired.

帆布層芯輸送帶的修補

Repair of canvas core conveyor belt

修補方式根據損壞的狀況，按下表選擇相應的修補方式：

Repair method according to the damage condition, select the corresponding repair method according to the following table:

損壞狀況損壞程度修補方式蓋膠損傷損傷僅在蓋膠，沒傷及帶坯不需修補蓋膠有損傷并傷及帶坯冷壓 硫化修補帶坯損傷帶坯損傷點小于帶層數量的1/2

Damage condition damage degree repair method the damage of the cover rubber is only in the cover rubber, and there is no need to repair the belt blank. The cover rubber is damaged and the belt blank is damaged by cold pressing vulcanization. The damage point of the belt blank is less than 1 / 2 of the number of belt layers

冷壓硫化修補帶坯損傷點大于帶層數量的1/2

The damage point of cold press vulcanization repair belt blank is greater than 1 / 2 of the number of belt layers

硫化板修補帶坯損傷范圍超過1/3帶寬切除損傷部分，

The damage range of vulcanized plate repair strip blank exceeds 1 / 3 of the bandwidth, and the damaged part is removed,

重新接料接頭損傷僅損及蓋膠冷壓硫化修補損及帶坯切除損傷部分，

The damage of rejoining joint only damages the damaged part of cover rubber cold press vulcanization repair and belt blank removal,

重新接料縱向裂縫裂縫較短硫化板修補裂縫較長加新帶重新接頭修補材料

The longitudinal crack of reconnection material is shorter, the repair crack of vulcanized plate is longer, and a new belt reconnection repair material is added

（1）硫化板修補：蓋膠、膠粘劑、帆布加強層（與主帶相同的帆布）。

(1) Vulcanized plate repair: cover glue, adhesive and canvas reinforcing layer (the same canvas as the main belt).

（2）冷壓硫化修補：蓋膠、填充膠、緩沖膠、膠粘劑。

(2) Cold press vulcanization repair: cover glue, filling glue, buffer glue and adhesive.

（3）蓋膠損傷的修補

(3) Repair of cover glue damage
