(1)工作時無滑動，有準確的傳動
(1) There is no sliding during operation, and there is accurate transmission
(2)傳動效率高，效果好
(2) High transmission efficiency and good energy-saving effect
(3)傳動比范圍大，結構緊湊
(3) Large transmission ratio range and compact structure
(4)維護保養方便，運轉費用低
(4) Convenient maintenance and low operation cost
(5)惡劣環境條件下仍能正常工作
(5) It can still work normally under harsh environmental conditions
同步輪的選型步驟
Selection steps of synchronous wheel
同步帶傳動機構一般按以下步驟進行計算與選型
The synchronous belt transmission mechanism is generally calculated and selected according to the following steps
(1)設計條件
(1) Design conditions
同步帶傳動設計,通常都是在以下已知條件下進行的
The design of synchronous belt transmission is usually carried out under the following known conditions
①同步帶需要傳遞的功率
① Power to be transmitted by synchronous belt
②主動輪轉速、從動輪轉速或傳動比
② Driving wheel speed, driven wheel speed or transmission ratio

③同步帶輪安裝距離;
③ Installation center distance of synchronous pulley;
④工作條件等
④ Working conditions, etc
需要計算選型確定的項目包括
Items to be calculated and selected include
同步帶節距、寬度、節線長度、實際距、同步帶輪齒數等,并將各參數用符號表示再向制造商訂購?fù)綆?、同步帶輪?br /> Timing belt pitch, width, pitch length, actual center distance, number of teeth of timing belt, etc. all parameters are represented by symbols, and then order timing belt and timing belt pulley from the manufacturer.
（2）根據轉速、功率選定同步帶帶型
(2) The timing belt type is selected according to the speed and power
同步帶帶型選型就是根據同步帶所需要傳遞的負載功率及主動輪轉速選擇合適的同步帶齒型及節距
The selection of synchronous belt type is to select the appropriate synchronous belt tooth type and pitch according to the load power and driving wheel speed that the synchronous belt needs to transmit
同步帶不同節距齒型的同步帶其單位寬度所能夠傳遞的功率是不同的，同一規格的同步帶在不同的轉速下所能夠傳遞的功率也不同。為了方便用戶正確地選用同步帶,制造商對不同類型、不同節距的同步帶在不同轉速下能夠傳遞的功率制成圖表，用戶可以根據圖表接選用合適的同步帶類型和節距。
Synchronous belts with different pitch tooth types can transmit different power per unit width, and synchronous belts of the same specification can transmit different power at different speeds. In order to facilitate users to correctly select synchronous belts, the manufacturer makes charts for the power that can be transmitted by synchronous belts of different types and pitches at different speeds. Users can select appropriate synchronous belt types and pitches according to the charts.
