1. Due to insufficient baffle length, the baffle length should be adjusted and lengthened until the material on the conveyor belt is stable.

2.裙邊開檔不合適所致。裙邊開檔應該是輸送帶寬度的2/3—3/4，塊狀物料時應窄一些。裙邊更好呈扇形（開口順著運行方向），并能調整開度大小。

2. Improper opening of skirt. The opening of skirt should be 2 / 3-3 / 4 of the width of conveyor belt, and the width of block material should be narrower. The skirt should be fan-shaped (opening along the running direction), and the opening can be adjusted.

大傾角擋邊輸送帶損傷原因？

Damage reason of conveyor belt with large inclination angle?

3.輸送帶和擋板的間隔不合適。先把擋板的輸送帶運行方向一側與輸送帶相觸，之后慢慢加大間隔到適當位置，以減少擋板對輸送帶的磨損。

3. The distance between conveyor belt and baffle is not suitable. First, contact the running direction side of the baffle belt with the conveyor belt, and then slowly increase the interval to the appropriate position to reduce the wear of the baffle to the conveyor belt.

4.投料方向不合適，即物料落下的方向與輸送帶運行方向不同，以致產生橫向力，使輸送帶跑偏或受磨損加劇，應調整落料方向。

4. The feeding direction is not suitable, that is, the material falling direction is different from the running direction of the conveyor belt, resulting in transverse force, which makes the conveyor belt deviate or suffer from wear aggravation, so the blanking direction should be adjusted.

5.擋板的材質不合適。擋板材質過硬，或者使用舊輸送帶而帆布露出，以致直接與輸送帶接觸，應選用合適的橡膠擋板。

5. The material of baffle is not suitable. If the baffle material is too hard, or the canvas is exposed due to the use of old conveyor belt, which directly contacts with the conveyor belt, appropriate rubber baffle should be selected.

6.物料的落料角度和落差不合適所致。應減少角度，使物料落在輸送帶上不彈跳。落差大而輸送帶受到很大沖擊時，應采取措施，以降低投料時的速度

6. The angle and drop of material are not suitable. The angle should be reduced to prevent the material from bouncing on the conveyor belt. Measures should be taken to reduce the feeding speed when the conveyor belt is impacted by large drop

7.物料的落料速度不對所致，由于物料的落料速度和輸送帶的速度調整得不好，物料落在輸送帶上的瞬間打滑，由此磨損上蓋膠時，要調整落料速度，使之與輸送帶速度一致。

7. The blanking speed of the material is not correct. Due to the poor adjustment of the blanking speed and the speed of the conveyor belt, the material will slip instantly when it falls on the conveyor belt. Therefore, when the upper cover rubber is worn, the blanking speed should be adjusted to make it consistent with the conveyor belt speed.

8.下托輥粘有物，不轉動或沒調整好，上蓋膠異常磨損，應采取如下幾種方法：安裝清掃器、清洗輸送帶、在返回輥上安裝橡皮套、修理或更換返回輥。

8. If the lower idler is stuck, does not rotate or is not adjusted properly, and the upper cover rubber is abnormally worn, the following methods should be adopted: install the sweeper, clean the conveyor belt, install rubber sleeve on the return roll, repair or replace the return roll.
