1. the characteristics of herringbone conveyor belt: the "herringbone" pattern on the belt surface is higher than the main body of belt. Patterns can be open or closed, and each pattern can be divided into high, medium and low. It is suitable for conveying powder, granular and small materials with inclination angle less than 40 degrees, and can also transport bagged materials.

2.帶狀輸送帶的特征：帶表面上的帶狀圖案高于帶體。模式可以分為高，中，低三種類型，并且根據排列間隔可以將每個模式分為稀疏和密集形式。使用時，適合水平傾角≤30度的包裝材料的水平運輸。如果在凹槽情況下，可以更換人字形圖案。

2. characteristics of belt conveyor belt: the belt pattern on the belt surface is higher than the belt body. Patterns can be divided into three types: high, medium, low, and each pattern can be divided into sparse and dense forms according to the arrangement interval. When used, it is suitable for horizontal transportation of packaging materials with horizontal inclination angle ≤ 30 degrees. If in the case of grooves, the herringbone pattern can be replaced.

3.輸送帶顆粒狀和麻點狀的特征：在帶子表面發(fā)現高于帶狀體或凹入的嵌入式帶狀體的顆粒狀圖案?？右部梢灾瞥煞娇?，棱柱和布樣。使用凸粒狀圖案適合于軟包裝或有抓地力的材料（例如紙板箱）或無滑動運輸的材料?？蛹y模式適用于傾角≤45度的谷物運輸。

3. characteristics of belt grain and pitting: the granular pattern higher than the belt or concave embedded ribbon is found on the belt surface. Pits can also be made into square holes, prisms and cloth samples. Use convex grain patterns for soft packaging or grip materials (such as cardboard boxes) or materials without sliding transport. Pit pattern is suitable for grain transportation with inclination angle less than 45 degrees.

4.扇形傳送帶的特征：傳送帶表面顯示半扇形（或1/4圓形）圖案。當帶子上的花紋溝打入風扇（或半圓形）時，是高花紋。適用于傾角≤60度的粉狀，顆粒狀，塊狀物料的輸送。

4. characteristics of sector conveyor: the surface of conveyor belt shows a semi fan (or 1/4 circle) pattern. When the groove on the belt is driven into the fan (or semicircular), it is high pattern. It is suitable for conveying powder, granular and block materials with inclination angle ≤ 60 degrees.
