1、自動拖輥調偏：當保送帶跑偏范圍不大時，可在保送帶跑偏處，裝置調心拖輥。
1. Auto-roll deflection adjustment: When the range of deviation of the belt is not large, the center-adjusting roll can be installed at the deviation of the belt.
2、恰當拉緊調偏：當保送帶跑偏忽左忽右，方向不定時闡明保送帶過松，可恰當調整拉緊安裝以消弭跑偏。
2. Proper tightening and deflection adjustment: When the delivery belt runs left and right, and the direction is uncertain, it is explained that the delivery belt is too loose, and the tightening installation can be adjusted appropriately to avoid running off.
3、單側立輥調偏：保送帶一直向一側跑偏，可在范圍內加裝若干立輥，使膠帶復位。
3. One-side vertical roll deflection adjustment: the belts run to one side all the time. Several vertical rollers can be installed in the range to make the belts reset.
4、調整滾筒調偏：保送帶在滾筒處跑偏，檢查滾筒能否異?；蚋Z動，調整滾筒程度位置正常轉動，消弭跑偏。
4. Adjust the deviation of the drum: the delivery belt runs away at the drum, check whether the drum can move abnormally or not, adjust the drum to the normal rotation of the degree position, eliminate the deviation.
5、校正保送帶接頭調偏；保送帶跑偏一直一個方向，且大跑偏在接頭處，可校正保送帶接頭與保送帶中線垂直消弭跑偏
5. Correct the deviation of the joint of the delivery belt; the deviation of the delivery belt is always in one direction, and the maximum deviation is at the joint, which can correct the vertical deviation between the joint of the delivery belt and the midline of the delivery belt.
6、墊高拖輥調偏：保送帶跑偏方向、間隔一定，可在跑偏方向的對側墊高拖輥若干組，消弭跑偏。
6. Adjusting the deviation of the tow rollers with high cushion: if the direction and interval of the belt are fixed, several groups of tow rollers can be cushioned on the opposite side of the deviation direction to eliminate the deviation of the tow rollers.
7、調整拖輥調偏：保送帶跑偏方向一定，檢查發現拖輥中線與保送帶中線不垂直，就可調整拖輥，消弭跑偏。
7. Adjust the deviation of the tow roll: The direction of the running deviation of the tow belt is certain. If it is found that the middle line of the tow roll is not perpendicular to the middle line of the tow belt, the tow roll can be adjusted to eliminate the deviation of the tow roll.
8、消弭隸屬物調：保送帶跑偏點不變，發現拖輥、滾筒粘有隸屬物，就要肅清后消弭跑偏。
8. Eliminate subordinate adjustments: the deviation point of the escort belt remains unchanged. If it is found that there are subordinate objects in the tow rollers and drums, it is necessary to eliminate the deviation after cleaning up.
9、校正給料跑偏：膠帶輕載不偏，重載跑偏，可調整給料重量及位置消弭跑偏。
9. Correction of feeding deviation: the tape is not deviated under light load and heavy load. The weight and position of feeding can be adjusted to eliminate the deviation.
10、校正支架調偏：保送帶跑偏方向、位置固定、跑偏嚴重可調整支架的程度和垂直度，消弭跑偏。
10. Adjusting the deflection of the support: the direction, position and serious deflection of the escort belt can adjust the degree and verticality of the support to eliminate the deflection.
This article is written by food grade conveyor belt. For more products and more details, please pay attention to our official website: http://www.ujkdbkh.cn. Your patronage is a great support to us.
