The existing conveyor belt has the advantages of frame rubber layer, middle layer, rubber and rubber covering, and its skeleton layer is not heat-resistant canvas material. This conveyor belt is only suitable for conveying high-temperature materials, but in steel, cement, chemical and other industries, it is mainly used to transport sinter, coke, cement, lime and other materials, because these materials are at higher temperatures. Material, such as sintering temperature from 500 to 800, emission, and some can even be achieved. This rubber conveyor belt can not withstand high temperature combustion, and there will be a lot of loss on the surface for a long time. It will cause damage to the skeleton material and reduce the intensity of the tape. The service life of the belt reduces the use efficiency and increases the use cost.

　　通過技術改進,產品創新性能,工業帶設計的自底向上的骨架層覆蓋少膠層,中間層的層下涂層組成,它的骨架和配備上下兩邊覆蓋橡膠集成橡膠的結構,這種結構的主要特征在于其骨架和已經抵抗燃燒層覆蓋膠也裝有玻璃纖維,或介于多胺與冷料之間的高強度保溫層，其耐燃層為丁苯材料，厚度為2- 6mm，耐熱玻璃纖維帆布材料骨架為1-6層，每層之間采用高溫苯乙烯-丁二烯橡膠粘結而成。通過以上結構的整體布置，可以達到非常明顯的應用效果:

　　Through technological improvement, product innovation performance, the bottom-up skeleton layer of industrial belt design covers at least rubber layer, and the undercoat of the middle layer is composed of the skeleton and the structure equipped with rubber integrated rubber covering on both sides of the upper and lower sides. The main characteristics of this structure are that its skeleton and the rubber covering that has resisted burning layer are also equipped with glass fibers, or The high-strength insulating layer between polyamine and cold material is made of butadiene-styrene with a thickness of 2-6 mm and a skeleton of heat-resistant glass fibre canvas material of 1-6 layers. The high-temperature styrene-butadiene rubber is used to bond each layer. Through the overall arrangement of the above structures, very obvious application results can be achieved.

　　，炭化層與高溫紅熱材料接觸后可迅速形成微孔炭化層，防止熱量傳遞到內帶，保護骨架層。炭化層具有阻燃、耐磨等性能。

　　Firstly, microporous carbonization layer can be formed rapidly after contact between carbonization layer and high temperature red-hot material to prevent heat transfer to inner zone and protect skeleton layer. The carbonized layer has the properties of flame retardant and wear resistance.

　　其次，選用強度損失小、不變形的改性玻璃纖維帆布等無機改性材料作為高溫下的骨架材料。這種新型的帆布結構不僅保證了帶體所需的強度，而且提高了帆布的抗彎性和橡膠與骨架材料的附著力。

　　Secondly, inorganic modified materials such as glass fiber canvas with low strength loss and no deformation are selected as the skeleton materials at high temperature. This new canvas structure not only guarantees the strength required by the belt body, but also improves the bending resistance of canvas and the adhesion between rubber and skeleton material.

　　第三,框架層采用高溫粘合劑,它解決問題的低粘附強度較低的層之間的高溫,并確保帶的層之間的粘附強度仍然穩定在160℃,這是兩倍多之間的粘附強度較低的層的普通耐熱輸送帶在同一狀態。

　　Thirdly, the frame layer uses high temperature adhesive, which solves the problem of high temperature between layers with low adhesion strength, and ensures that the adhesion strength between layers is still stable at 160 C, which is more than twice the common heat-resistant conveyor belt of layers with low adhesion strength in the same state.

　　創新的產業結構重型傳送帶制造商通過以上,確保船舶的正常使用磁帶在高溫條件下,延長使用壽命,并且可以適應傳輸溫度200600℃,立即在800℃的高溫材料的各種工況,其良好的耐燃性和在相同條件下使用的普通耐高溫輸送帶的使用壽命是普通耐高溫輸送帶的3-4倍，這種耐燃輸送帶由于其良好的性能，可適用于燒結礦、焦炭、水泥熟料、、高溫石灰等材料。

　　The innovative industrial structure of heavy-duty conveyor belt manufacturers through the above, to ensure that the normal use of the ship tape in high temperature conditions, prolong service life, and can adapt to the transmission temperature of 200 to 600 C, immediately at 800 C of high-temperature materials under various working conditions, its good flame resistance and the use of common high-temperature conveyor belt under the same conditions. The service life of the conveyor belt is 3-4 times as long as that of the ordinary high-temperature-resistant conveyor belt. Because of its good performance, the conveyor belt can be applied to sinter, coke, cement clinker, high-quality, high-temperature lime and other materials.
