Shandong layered fabric conveyor belt is divided into three types

1、棉帆布輸送帶：

1. Cotton canvas conveyor belt:

適用于短距離和中等負載條件下的物料輸送，張力相對較低，承重有限

It is suitable for material transportation under short distance and medium load conditions. The tension is relatively low and the load is limited

2、尼龍輸送帶：\ n 尼龍輸送帶具有帶薄、耐沖擊、凹槽成型性好、柔韌性好、使用壽命長等特點。適用于中長距離、高負荷、高速條件下的物料輸送。

2. Nylon conveyor belt has the characteristics of long impact resistance and good service life. It is suitable for material transportation under medium and long distance, high load and high speed conditions.

3、滌綸輸送帶：

3. Polyester conveyor belt:

帶體模量高、伸長率小、熱穩定性好、耐沖擊、強度高、柔韌性好、使用壽命長，適用于中長距離、高自由度、高速輸送物料。

The belt has high modulus, small elongation, good thermal stability, impact resistance, high strength, good flexibility and long service life. It is suitable for medium and long distance, high degree of freedom and high-speed transportation of materials.

山東聚酯輸送帶

Shandong polyester conveyor belt

滌綸輸送帶是由多層滌綸（或徑向滌綸，緯向滌胺）帆布按一定方式粘合而成，上下罩覆有強度高、彈性好的磨膠。適用于中長距離、高載重、高速運輸。

Polyester conveyor belt is made of multi-layer polyester (or radial polyester, weft polyester amine) canvas bonded in a certain way, and the upper and lower covers are covered with grinding glue with high strength and good elasticity. It is suitable for medium and long distance, high load and high-speed transportation.

種類：Type:

普通型、耐油型、耐酸堿型、耐熱型、耐高溫型、耐燃燒型、阻燃型、耐寒型、耐磨型。

Ordinary type, oil resistant type, acid and alkali resistant type, heat resistant type, high temperature resistant type, combustion resistant type, flame retardant type, cold resistant type and wear resistant type.

規格型號：Specification and model:

面料型號：EP100、EP150、EP200、EP250、EP300、EP350、EP400

Fabric model: EP100, EP150, ep200, ep250, ep300, ep350, ep400

單層織物強度：100、150、200、250、300、350、400(N/mm)

Single layer fabric strength: 100, 150, 200, 250, 300, 350, 400 (n / mm)

帶寬：300-3200mm

Bandwidth: 300-3200mm

層數：2-8層Number of floors: 2-8

涂膠：1.5+1.5、3.0+1.5、4.0+2.0、4.5+1.5、4.5+3.0、6.0+1.5、6.0+3.0

Gluing: 1.5 + 1.5, 3.0 + 1.5, 4.0 + 2.0, 4.5 + 1.5, 4.5 + 3.0, 6.0 + 1.5, 6.0 + 3.0

特征 ：features:

1、帶體模量高，伸長率小。

1. The belt has high modulus and low elongation.

2、良好的熱穩定性、抗沖擊性和高強度。

2. Good thermal stability, impact resistance and high strength.

3. 優良的柔韌性和長使用壽命。

3. Excellent flexibility and long service life.

所以建議使用滌綸輸送帶?。?！

Therefore, it is recommended to use polyester conveyor belt!!!

聚酯輸送帶又稱EP輸送帶、耐磨輸送帶、自動輸送帶、水泥輸送帶，具有體模量高、伸長率低、耐熱穩定性好、耐沖擊，適用于中長距離和相對高剪裁，在高速條件下輸送物料。

Polyester conveyor belt, also known as EP conveyor belt, wear-resistant conveyor belt, automatic conveyor belt and cement conveyor belt, has high bulk modulus, low elongation, good heat stability and impact resistance. It is suitable for medium and long distance and relatively high cutting and conveying materials at high speed.

山東聚酯輸送帶（EP輸送帶）用于煤炭、礦山、港口、冶金、電力、化工等領域輸送物料。

Shandong polyester conveyor belt (EP conveyor belt) is used to transport materials in coal, mining, port, metallurgy, electric power, chemical industry and other fields.

滌綸輸送帶分類

Classification of polyester conveyor belt

①按包覆膠的性能分為耐寒耐酸、耐堿、耐油、耐磨等。

① According to the properties of coating adhesive, it can be divided into cold resistance, acid resistance, alkali resistance, oil resistance, wear resistance, etc.

②聚酯輸送帶按使用環境不同分為橡膠輸送帶，包括（普通型、耐熱型、阻燃型、耐燃型、耐酸堿型、耐油型）、耐熱型輸送帶、耐寒輸送帶、耐酸堿輸送帶、耐油輸送帶、食品輸送帶等型號。其中，普通輸送帶和食品輸送帶上的低蓋膠厚度為3.0mm，下蓋膠為1.5mm；耐熱輸送帶、耐寒輸送帶、耐酸堿輸送帶、耐油輸送帶低覆蓋膠厚度為4.5mm，下覆蓋膠厚度為2.0mm。

② Polyester conveyor belts can be divided into rubber conveyor belts according to the use environment, including (ordinary type, heat resistant type, flame retardant type, flame resistant type, acid and alkali resistant type, oil resistant type), heat resistant conveyor belt, cold resistant conveyor belt, acid and alkali resistant conveyor belt, oil resistant conveyor belt, food conveyor belt and other models. Among them, the thickness of low cover glue on ordinary conveyor belt and food conveyor belt is 3.0mm, and the thickness of lower cover glue is 1.5mm; The thickness of low covering glue of heat-resistant conveyor belt, cold resistant conveyor belt, acid and alkali resistant conveyor belt and oil resistant conveyor belt is 4.5mm, and the thickness of lower covering glue is 2.0mm.

③根據使用環境的具體情況，上下覆蓋膠的厚度可增加1.5mm。

③ The thickness of the upper and lower covering glue can be increased by 1.5mm according to the specific conditions of the service environment.
