1、機頭進新帶、機頭出舊帶方式
1. Mode of new belt entering and old belt exiting the machine head
在輸送機機頭前新帶的上面制作搭設回收舊帶的簡易支撐架，將牽引裝置安裝在輸送機機頭，換帶時，將舊帶自輸送機機頭上面斷開，將新舊帶一頭連接好，將舊帶另一頭與牽引裝置連接好，通過牽引裝置完成新帶鋪設和舊帶拉出工作，完成新帶的連接，具體更換法如圖4所示。
Make and erect a simple support frame for recycling the old belt on the new belt in front of the conveyor head, install the traction device on the conveyor head, disconnect the old belt from the conveyor head when changing the belt, connect one end of the old and new belt, connect the other end of the old belt with the traction device, complete the laying and pulling out of the new belt through the traction device, and finally complete the connection of the new belt, The specific replacement method is shown in Figure 4.
適用條件：此方式適用于平巷運輸方式和上運、下運運輸方式輸送帶的更換。
Applicable conditions: this method is applicable to the replacement of conveyor belt in drift transportation and up and down transportation.
2、機尾進新帶、機尾出舊帶方式
2. Tail in new belt and tail out old belt
在機尾滾筒后新輸送帶上面制作搭設一個回收舊帶簡易支撐架，將牽引裝置安裝在輸送機機尾距滾筒一定距離地方，換帶時，將舊帶自輸送機機尾上面斷開，將新帶一頭與舊帶一頭連接好，將舊帶另一頭與牽引裝置連接好，通過牽引裝置完成新帶鋪設和舊帶拉出工作。
Make and erect a simple support frame for recycling the old belt on the new conveyor belt behind the tail drum, and install the traction device at a certain distance from the tail of the conveyor to the drum. When changing the belt, disconnect the old belt from the tail of the conveyor, connect one end of the new belt with one end of the old belt, and connect the other end of the old belt with the traction device, The laying of new belt and pulling out of old belt are completed through the traction device, and finally the connection of new belt is completed. The replacement method of entering new belt at the tail and exiting old belt at the tail is shown in Figure 5.
適用條件：此方式適用于平巷和上運運輸方式輸送帶更換。
Applicable conditions: this method is applicable to the replacement of conveyor belt in drift and upward transportation.
3、中間段進新帶、機尾出舊帶方式
3. New belt in the middle section and old belt out of the tail
在輸送機中間架上制作安裝一套簡易導向轉角裝置，將牽引裝置安裝在機尾距滾筒一定距離地方，換帶時，將舊帶自機尾斷開，將舊帶一頭與牽引裝置連接好自輸送機下面拉出，當舊帶另一頭拉簡易導向轉角裝置處時，再將新帶一帶頭與其連接好，通過牽引裝置完成新帶鋪設和舊帶拉出工作，完成新帶的連接。中間段進新帶、機尾出舊帶方式更換法如圖6所示。
A set of simple guide angle device shall be fabricated and installed on the middle frame of the conveyor, and the traction device shall be installed at a certain distance from the tail of the machine to the drum. When changing the belt, disconnect the old belt from the tail, connect one end of the old belt with the traction device and pull it out from under the conveyor. When the other end of the old belt is pulled to the simple guide angle device, connect the first end of the new belt with it, Complete the laying of new belt and pulling out of old belt through the traction device, and finally complete the connection of new belt. The replacement method of new belt in the middle section and old belt out of the tail is shown in Figure 6.
適用條件：此方式適用于平巷、上運、下運方式輸送帶的更換。
Applicable conditions: this method is applicable to the replacement of conveyor belt in drift, up transportation and down transportation.
4、中間段進新帶、中間段出舊帶方式
4. Mode of entering the new belt in the middle section and exiting the old belt in the middle section
將牽引裝置安裝在輸送機中間段，在進新帶、出舊帶處中間架上各安裝一套簡易導向轉角裝置，換帶時把舊帶自輸送機中間架上帶（或下帶）斷開，接著舊帶一頭與牽引裝置連接好，通過牽引裝置完成新帶鋪設皮帶和舊帶拉出工作，完成新輸送帶連接，中間段進新帶、中間段出舊帶方式更換法如圖7所示。
Install the traction device in the middle section of the conveyor, install a set of simple guide angle device on the middle frame at the place where the new belt enters and the old belt exits. When changing the belt, disconnect the old belt from the upper belt (or lower belt) of the middle frame of the conveyor, then connect one end of the old belt with the traction device, lay the new belt and pull out the old belt through the traction device, and finally complete the connection of the new conveyor belt, The replacement method of new belt in the middle section and old belt out of the middle section is shown in Figure 7.
適用條件：此方式適用于平巷、上運、下運方式輸送帶的更換。
Applicable conditions: this method is applicable to the replacement of conveyor belt in drift, up transportation and down transportation.
