Rubber ring conveyor belt refers to the belt has been made into a ring conveyor belt without joint in the production process. The strength of the belt core joint can reach 90% of the strength of the belt body, and there is no obvious joint defect on the surface of the tape. Therefore, the belt transportation is balanced and the use elongation is small; The core is made of * * cotton or Uygur cotton woven canvas.

技術指標：

Technical index:

橡膠環形輸送帶按帶體拉伸強度可分為M、L、H等型號、其相應拉伸強度如下：

According to the tensile strength of the belt, rubber ring conveyor belt can be divided into m, l, h and other models, and its corresponding tensile strength is as follows:

M型：其帶芯系用**維棉交織帆布、一般2-6層、膠厚度約7.5mm-20mm; L型系用NN-200型尼帆布(或聚酯帆布>作強力層、一般2-6層、膠厚度7.500mm-20mm。

M type: the core system is made of * * cotton woven canvas, generally 2-6 layers, and the glue thickness is about 7.5mm-20mm; The L-type is made of NN-200 type canvas (or polyester canvas > as the strong layer, 2-6 layers in general, and the glue thickness is 7.500mm-20mm).

H型：用NN-300型尼龍帆布(或聚酯帆布>作強力層、一般2-4層、膠帶總厚度7.500mm-20mm。

Type H: nn-300 nylon canvas (or polyester canvas > is used as strength layer, 2-4 layers in general, and the total thickness of tape is 7.500mm-20mm).

膠帶**大寬度為3100mm、按照作用性能、可提供普通型、耐熱型、耐寒型(不低于-4℃>耐酸堿型、導靜電型、耐高溫型(不高于150℃>及衛生型等。

The tape * * is 3100mm wide, and can provide ordinary, heat-resistant, cold resistant (not less than-4 ℃ > acid alkali resistant, electrostatic, high temperature resistant (not higher than 150 ℃ > and sanitary type, etc.) according to the function performance.

在使用環形輸送帶時要注意以下事項：

When using the ring conveyor belt, the following matters shall be noted:

<1>不要讓物料覆蓋托輥、保持托輥潤滑、以免造成其回轉不靈通;

<1> Do not let the material cover the roller, keep the roller lubricated, so as to avoid its rotation is not smooth;

<2>環形輸送帶不要超負荷啟動;

<2> The ring conveyor belt shall not be started under overload;

<3>當我們發現環形輸送帶跑偏時、要及時糾正、以免造成環形輸送帶的斷裂、影響正常工作;

<3> When we find out that the belt is out of alignment, it should be corrected in time to avoid the fracture of the belt and affect the normal operation;

<4>發現環形輸送帶有破損要及時修補、以免破損擴大、影響其正常運轉;

<4> If the ring conveyor belt is found to be damaged, it should be repaired in time to avoid the damage expanding and affecting its normal operation;

<5>要注意避免機架、支柱或塊狀物料對環形輸送帶阻滯。

<5> Care should be taken to avoid blocking the belt by rack, strut or block material.

pvc環形輸送帶介紹：

PVC ring conveyor belt introduction:

PVC輸送帶其膠面材質為聚氯乙烯(Polyvinylchloride，PVC)，其構成為聚酯纖維布和聚氯乙烯膠構成。其工作溫度一般為-10°到+80°，其接頭方式一般為齒形接頭，橫向穩定性良好適宜各種復雜環境下傳輸。

PVC conveyor belt is made of polyvinylchloride (PVC), which is made of polyester fiber cloth and PVC adhesive. The operating temperature is generally -10 ° To +80 °， The joint is generally international tooth joint, and the lateral stability is good and suitable for transmission in various complex environments.
