(1) Large plate vulcanizer: The large plate vulcanizer is rectangular frame structure with a width of 1.4-2.2m and a length of 8-10m. The largest flat plate in the world is 3.8m in width and 15.6m in length. The large plate vulcanizer is basically driven by hydraulic pressure. The heat source is steam and hot oil. The plate pressure is provided by the hydraulic system.

（2） 鼓式硫化機：鼓式硫化機可進行大傾角輸送帶的接連硫化，規范φ700Χ1500mm到φ1500Χ2600mm，世界上大的鼓式硫化機為φ2000Χ3200mm。鼓式硫化機經過 轉鼓對大傾角輸送帶進行加熱，以膠帶或鋼帶進行加壓，硫化壓力小于大平板硫化機。鼓式硫化機高，出產功率低，目前多限硫化薄層大傾角輸送帶。

(2) Drum vulcanizing machine: Drum vulcanizing machine can carry out continuous vulcanization of conveyor belt with large inclination angle. Specification_700_1500 mm to_1500_2600 mm. The largest drum vulcanizing machine in the world is_2000_3200 mm. The drum vulcanizer heates the conveyor belt with large inclination angle through the drum, and pressurizes it with the belt or steel belt. The vulcanization pressure is less than that of the large plate vulcanizer. Drum vulcanizing machine has high price and low output power. At present, Multi-Limit vulcanizing thin layer conveyor belt with large inclination is used.

（3） 接連式平板硫化機：接連式平板硫化機有兼平板硫化機和鼓式硫化機的特點，可接連硫化各種高強度、大厚度大傾角輸送帶，特別適合于硫化和塑化需冷卻出鍋 的整芯大傾角輸送帶。 接連式平板硫化機有上下各二塊熱板，熱板與帶坯之間各加有一條環形滾子鏈和環形鋼帶，滾子鏈和鋼帶各有一套獨立的翻滾設備。硫化時帶坯被夾在兩條鋼帶之間由 熱板經過熱轉導加熱而硫化，并經過熱板、滾子鏈和鋼帶對硫化帶坯加壓，硫化時上下兩環形鋼帶與帶坯一同接連工作完成帶坯的接連硫化。

(3) Continuous plate vulcanizing machine: Continuous plate vulcanizing machine has the characteristics of both plate vulcanizing machine and drum vulcanizing machine. It can be used to vulcanize various high strength, large thickness and large inclination conveyor belts, especially for whole core conveyor belts with large inclination which need to be cooled out of the pot during vulcanization and plasticization. There are two hot plates in the continuous plate vulcanizer, one ring roller chain and one ring steel belt between the hot plate and the strip. Each roller chain and the strip has a set of independent rolling equipment. During vulcanization, the strip is clamped between two strips and vulcanized by heat transfer heating of the hot plate. The strip is pressurized by hot plate, roller chain and strip. During vulcanization, the upper and lower ring strips work together with the strip to complete the continuous vulcanization of the strip.
