1. Deviation caused by installation error

1）輸送帶接頭不平直。

1) The belt joint is not straight.

造成輸送帶兩邊張力不均勻，輸送帶往張緊力大的一邊跑偏，針對這種情況，可以針對調整轉動滾筒或改向滾筒的兩邊的張緊力來，如仍調整不過來需對輸送帶接頭重接。

The tension on both sides of the conveyor belt is uneven, and the conveyor belt deviates to the side with large tension. In view of this situation, the tension on both sides of the rotating drum or the steering drum can be adjusted to eliminate it. If the adjustment still fails, the conveyor belt joint needs to be reconnected.

2）機架歪斜。

2) The rack is skewed.

機架歪斜包括機架線歪斜和機架兩邊高低傾斜，這兩種情況都會造成嚴重跑偏，并且很難調整。輸送機線歪斜，頭尾調正后，中間部位的跑偏若還糾正不過來，需對機架重新安裝。

The frame skew includes the frame center line skew and both sides of the frame high and low tilt, both of which will cause serious deviation, and it is difficult to adjust. If the center line of the conveyor is skewed and the deviation of the middle part can not be corrected after the head and tail are adjusted, the rack shall be re installed.

3）導料槽兩側的橡膠板壓力不均勻。

3) The pressure of the rubber plate on both sides of the guide groove is not uniform.

由于橡膠板壓力不均勻，造成輸送帶兩邊運行阻力不一致，引起輸送帶跑偏，這種情況的處理相對較容易，重新調整兩側橡膠板壓力即可。

Due to the uneven pressure of the rubber plate, the running resistance on both sides of the conveyor belt is inconsistent, which causes the conveyor belt to deviate. It is relatively easy to deal with this situation. It is enough to readjust the pressure of the rubber plate on both sides.

2.輸送帶運行中的跑偏

2. Belt running deviation

1）滾筒、托輥粘料引起的跑偏。

1) Deviation caused by sticking of roller and idler.

帶式輸送機在運行一段時間后，由于礦料具有一定的粘性，部分礦粉會粘沾在滾筒和托輥上，使得滾筒或托輥局部筒徑變大，引起輸送帶兩側張緊力不均勻，造成輸送帶跑偏。

After the belt conveyor has been running for a period of time, some mineral powder will stick to the roller and idler due to the certain viscosity of the mineral material, which makes the local diameter of the roller or idler larger, resulting in the uneven tension on both sides of the conveyor belt and the deviation of the conveyor belt.

2）輸送帶松弛引起的跑偏。

2) Deviation caused by loose conveyor belt.

調整好的輸送帶在運行一段時間后，由于輸送帶拉伸產生變形或老化，會使張緊力下降，輸送帶松弛，引起跑偏。

After the adjusted conveyor belt runs for a period of time, due to the permanent deformation or aging of the conveyor belt, the tension will drop, the conveyor belt will relax, causing deviation.

3）礦料分布不均勻引起的跑偏。

3) Deviation caused by uneven distribution of mineral materials.

如果輸送帶空轉時不跑偏，重負荷運轉時跑偏，說明礦料在輸送帶兩邊分布不均勻。礦料分布不均主要是礦料下落的方向和位置不正確引起的，如果礦料偏到左側，則輸送帶向右跑偏；反之亦然。、

If the conveyor belt does not deviate when it is idling and deviates when it is running under heavy load, it means that the mineral material is not evenly distributed on both sides of the conveyor belt. The uneven distribution of ore material is mainly caused by the incorrect direction and position of ore material falling. If the ore material deviates to the left, the conveyor belt will deviate to the right; And vice versa

4）運行中振動引起的跑偏。

4) Running deviation caused by vibration during operation.

帶式輸送機在運行時的機械振動是不可避免的，運行速度越快，振動越大，造成的輸送帶跑偏的可能性也越大。在帶式輸送機中，托輥的徑向跳動引起的振動對輸送帶跑偏影響大。

The mechanical vibration of belt conveyor in operation is inevitable. The faster the running speed is, the greater the vibration is, and the greater the possibility of belt deviation is. In the belt conveyor, the vibration caused by the radial runout of the idler has a great influence on the belt deviation.
