煤礦用阻燃抗靜電pvc輸送帶、PVG整芯輸送帶采用整體帶芯作為骨架材料，經浸漬，上下覆蓋膠具有極女子的抗靜電、阻燃等性能的PVG(橡膠面)或PVG(塑膠面)材料而成。
Flame retardant and antistatic PVC conveyor belt and PVG whole core conveyor belt for coal mine are made of PVG (rubber surface) or PVG (plastic surface) material with excellent antistatic and flame retardant properties by impregnating and covering with rubber.
煤礦用輸送帶用途：產品具用不脫層、難燃燒、導靜電、抗縱向撕裂、抗沖擊力、抗水侵蝕等優良性能，適用于煤礦、井下及其它易燃場合，輸送煤炭、化工類等物品。PVC整芯輸送帶用于傾角16°以下的干燥條件的工作環境，PVG整芯輸送帶可用于潮濕的工作境。
Application of conveyor belt for coal mine: the product has excellent properties such as non delamination, difficult to burn, static electricity conduction, anti longitudinal tearing, anti impact, anti water erosion, etc. it is suitable for coal mine, underground and other flammable occasions to transport coal, chemical and other goods. PVC whole core conveyor belt can be used in dry working environment with inclination angle less than 16 ° and PVG whole core conveyor belt can be used in wet working environment.
PVC輸送帶有什么作用，有哪些裝置？PVC輸送帶在礦石運輸過程中，與其他作業相銜接，為保證相關的作業正常運轉，常在有的PVC輸送帶上安裝附設裝置，為整個生產過程的計量、服務。
What are the functions and devices of PVC conveying? In the process of ore transportation, PVC conveyor belt is connected with other operations. In order to ensure the normal operation of related operations, some PVC conveyor belts are often installed with attached devices to serve the measurement and safety of the whole production process.
1、皮帶秤
1. Belt scale
為加強礦山生產過程中的計劃管理工作，一般都要對每日進人的原礦量和產出的精礦量進行計量。這項工作除了一些小型廠礦采用人工計量的方法來完成外，大部分廠礦都采用在帶式輸送機上安裝皮帶秤、電子皮帶秤或核子秤來完成。
In order to strengthen the planning management in the process of mine production, it is generally necessary to measure the daily raw ore intake and concentrate output. In addition to some small factories and mines using manual measurement method to complete this work, most factories and mines use the belt scale, electronic belt scale or nuclear scale installed on the belt conveyor to complete.
電子皮帶秤多安裝于帶式PVC輸送帶底部，由秤架、稱重橋、托輥和傳感器等組成.因此，為保證稱量的準確，PVC輸送帶在運行過程中，皮帶不要發生跑偏，同時要及時附著在帶式輸送機和電子皮帶秤秤架、托輥上的物料。
Electronic belt scale is usually installed at the bottom of belt type PVC conveyor belt, which is composed of scale frame, weighing bridge, idler and sensor. Therefore, in order to ensure the accuracy of weighing, the belt should not deviate during the operation of PVC conveyor belt, and the materials attached to the scale frame and idler of belt conveyor and electronic belt scale should be removed in time.
核子秤是安裝于帶式輸送機上方的計童裝置，它雖與PVC輸送帶不發生接觸，但在操作PVC輸送帶時，人員盡可能不要靠近該裝置，以防止受到放射污染。
Nuclear scale is a child counting device installed on the top of belt conveyor. Although it does not contact with PVC conveyor belt, when operating PVC conveyor belt, personnel should not be close to the device as far as possible to prevent radiation pollution.
2、除鐵裝置
2. Iron removal device
在需要對礦石進行破碎的運輸過程中(如在選礦廠)，為混入礦石中的鐵件，使破碎機運輸.通常在中、細碎機前的PVC輸送帶上設置除鐵裝置。目前常用的除鐵裝置有:
In the transportation process of ore crushing (e.g. in concentrator), in order to remove the iron mixed in ore and make the crusher transport safely, the iron removal device is usually set on the PVC conveyor belt in front of the medium and fine crushers. At present, the commonly used iron removal devices are as follows:
(1)自動除鐵裝置:由金屬探測器、電磁鐵、機械取出裝置等幾部分組成。
(1) Automatic iron removal device: it is composed of metal detector, electromagnet, mechanical removal device, etc.
(2)帶式電磁分離器:一般安裝在PVC輸送帶的卸料處，由機架、電磁鐵、電動滾筒、改向滾筒及傳送帶等部件組成。
(2) Belt type electromagnetic separator: generally installed at the discharge place of PVC conveyor belt, it is composed of frame, electromagnet, electric roller, steering roller and conveyor belt.
(3)懸垂式電磁分離裝置:一般由金屬探測器和電磁鐵組成，但當輸送的物料層很厚時，可增設滾筒式電磁分離器。懸垂式電磁分離器上、中部礦石中的鐵件，滾簡式電磁分離器下部礦石中的鐵件。
(3) Suspension type electromagnetic separation device: generally composed of metal detector and electromagnet, but when the conveying material layer is very thick, drum type electromagnetic separator can be added. The iron parts in the upper and middle ore are removed by the suspended electromagnetic separator, and the iron parts in the lower ore are removed by the rolling electromagnetic separator.
The above food grade conveyor belt is the content to share with you. For more wonderful content, please click http://www.ujkdbkh.cn Enter our website, or search our keywords, we will have more wonderful content to share with you!
