With the increasing use of mining materials, the corresponding mining scale is also increasing. In the production process, it is necessary to ensure the normal operation under the premise of safety. Therefore, it is very important for the stable operation of belt conveyor. A more detailed description of the smoother operation of the belt conveyor will be used:

　　帶式輸送機是采礦必不可少的：它們具有容量大，傳輸距離長，連續運輸?shù)葍?yōu)點，并可用于自動遙控。 因此，輸送機設備被廣泛使用，但是具有快速的自動化技術。 產量的增加和增加，對操作需求和效率的要求更高，生產過程中工作強度更高的大角度長距離帶式輸送機，目前的大傾角可以達到50度，但同時還有大傾角 ，必須特別注意設備的操作穩定性。 除了配置的制動設備外，還需要科學合理的布局以使皮帶輸送機設備更穩定地運行。

　　Belt conveyors are essential for Mining: they have the advantages of large capacity, long transmission distance, continuous transportation and can be used for automatic remote control. Therefore, conveyor equipment is widely used, but it has rapid automation technology. With the increase of production, the operation demand and efficiency are higher, and the working intensity is higher in the production process. At present, the maximum inclination angle of the large angle long-distance belt conveyor can reach 50 degrees, but at the same time, there is a large inclination angle. First of all, special attention must be paid to the operation stability of the equipment. In addition to efficient braking equipment, scientific and reasonable layout is also needed to make the belt conveyor equipment run more stably.

　　如果皮帶輸送機運輸大量礦物材料，則該材料將粘附在裙邊皮帶上，并且滑動力將導致整個機器向后下落。 這將導致異常事故。 為了避免此類問題，有必要配置可靠的保護。 換向裝置保證了大角度皮帶輸送機的穩定運行。 選擇的前提是在大工作能力下測量輸送機的滑動力矩，例如考慮到緊湊的結構和易于安裝的情況，并且機器空間過大。 從尾部裝載點到行駛前十米的距離，尾架和尾部中間框架的安裝角度減小到小于30度，從而使整機的安裝傾斜角小于 要加載的原始物料的動態傾倒角度。 物料穩定在橡膠帶上后，進入大傾角的工作狀態；

　　If the belt conveyor transports a large amount of mineral material, the material will adhere to the skirt belt and the sliding force will cause the whole machine to fall backward. This will lead to abnormal accidents. In order to avoid such problems, it is necessary to configure reliable protection. The reversing device ensures the stable operation of the large angle belt conveyor. The premise of selection is to measure the sliding moment of the conveyor under the maximum working capacity, for example, considering the compact structure and easy installation, and the machine space is too large. From the tail loading point to the ten meters before driving, the installation angle of the tail frame and the tail middle frame is reduced to less than 30 degrees, so that the installation inclination angle of the whole machine is less than the dynamic dumping angle of the original material to be loaded. After the material is stable on the rubber belt, it enters into the working state of large inclination angle.

　　為避免輸送帶在皮帶輸送機中滑動的問題，可以選擇高強度阻燃鋼絲繩芯抗撕裂輸送帶，以增加皮帶表面與皮帶主體之間的摩擦阻力。 深溝形狀。 在皮帶輪上，膠印滾筒上的凹槽角度為六十度，以增加物料與鋼絲繩輸送帶之間的側向壓力，從而防止整個機器在使用中使用 輸送帶。 承載能力需要與合適的加載機制相匹配，然后根據現場條件選擇合適的角度。 溜槽設計為鏟形，下料方向從垂直方向變?yōu)樗椒较颍瑥亩_保了順暢的輸送并減少了對皮帶的影響。  ;

　　In order to avoid the problem of belt sliding in the belt conveyor, high-strength flame-retardant steel cord tear resistant conveyor belt can be selected to increase the friction resistance between the belt surface and the belt main body. Deep groove shape. On the pulley, the groove angle on the offset roller is 60 degrees to increase the lateral pressure between the material and the wire rope conveyor belt, so as to prevent the whole machine from using the conveyor belt in use. The bearing capacity needs to match with the appropriate loading mechanism, and then select the appropriate angle according to the site conditions. The chute is designed as spade shape, and the blanking direction changes from vertical direction to horizontal direction, so as to ensure smooth transportation and reduce the impact on the belt. ;

　　另外，選擇合適的變頻軟啟動方式，并在上部皮帶上設置密閉保護裝置，以防止由于過大的傾斜角度而引起滾動狀況，密閉刮板置于中間。 下部皮帶的角度，以防止材料向機器滾動。 這些尾部對于輸送機的平穩運行非常重要。 合理的保護尾巴可以防止由于碎屑和石頭引起的皮帶偏移和皮帶斷裂等異常情況。 我們可以完全閉合尾巴；

　　In addition, select a suitable frequency conversion soft start mode, and set up a closed protection device on the upper belt to prevent rolling due to too large tilt angle. The closed scraper is placed in the middle. The angle of the lower belt to prevent material from rolling towards the machine. These tails are very important for the smooth operation of the conveyor. Reasonable tail protection can prevent belt deviation and belt fracture caused by debris and stones. We can close the tail completely;

　　后，增加存儲容量以減少帶式輸送機的頻繁運行，避免超載運行，嚴格控制物料的水分，其他生產和運輸環節中的水混合，膠帶圖案的磨損和修復，技術分析等 現場觀察，大浸入帶當機器以恒定速度運行時，由于材料和防滑橡膠輸送帶的摩擦阻力，滑動速度的增加會增加工業橡膠帶花紋的磨損。 如果不及時修理，則磁帶將無法傳送材料。 因此，有必要使用的橡膠冷粘接方法進行及時修補；

　　Finally, increase the storage capacity to reduce the frequent operation of the belt conveyor, avoid overload operation, strictly control the moisture content of the material, eliminate the water mixing in other production and transportation links, wear and repair of the belt pattern, technical analysis and other field observation. When the large immersion belt is running at a constant speed, due to the friction resistance of the material and the antiskid rubber conveyor belt, the sliding speed The increase of degree will increase the abrasion of industrial rubber belt pattern. If not repaired in time, the tape will not be able to transfer the material. Therefore, it is necessary to use a professional rubber cold bonding method for timely repair;
