1.橡膠同步帶由于使用年限長導致的正常磨損和失效
1. Normal wear and failure of rubber synchronous belt due to long service life
當橡膠同步輪的芯線使用壽命達到后，此時的同步帶出現失效是屬于正常情況。在經過2~3年乃更長時間的運轉后，由于芯線是使用壽命達到了極限導致的失效，屬于理想的同步帶失效模式。區別于由于長期運轉后，齒部出現磨損而失效這種模式則不屬于理想的同步帶失效模式。
When the service life of the core wire of the rubber synchronous wheel reaches, it is normal for the synchronous belt to fail. After 2 ~ 3 years or even longer operation, the failure of the core wire is caused by the service life reaching the limit, which belongs to the ideal synchronous belt failure mode. Different from the failure due to wear of the teeth after long-term operation, this mode does not belong to the ideal synchronous belt failure mode.
運行2到3年后的同步帶不需要采取任何改善措施，也會由于其芯線壽命與應用的不同，受各種外部客觀因素的影響不同，影響同步帶壽命的因素包括傳輸功率等級，環境，同步帶安裝張力，帶與輪的匹配，帶輪的質量水平，甚是如何切割、包裝、運輸和安裝同步帶。
After 2 to 3 years of operation, the synchronous belt does not need to take any improvement measures. Due to its different core wire life and application, it will be affected by various external objective factors. The factors affecting the synchronous belt life include transmission power level, environment, installation tension of synchronous belt, matching between belt and pulley, quality level of pulley, and even how to cut, pack Transport and install timing belt.
2.橡膠同步帶折曲失效
2. The rubber synchronous belt is bent and fails
橡膠同步帶因曲折失效模式有一個很顯而易見的表現，那就是其斷裂面呈直線排列。
There is an obvious manifestation of the zigzag failure mode of rubber synchronous belt, that is, its fracture surface is arranged in a straight line.
當橡膠同步帶芯線彎曲到非常小的直徑時，就會引起這種失效模式的發生。急劇的轉彎使同步帶芯線在巨大的壓力下彎曲和受損，影響同步帶的拉伸強度，這屬于更常見的一種失效模式，通常出現這種失效模式與同步帶操作不當、安裝張緊力過低、帶輪的直徑過小和帶輪里有異物等有關。

This failure mode occurs when the rubber synchronous belt core is bent to a very small diameter. Sharp turns bend and damage the synchronous belt core under great pressure, affecting the tensile strength of the synchronous belt, which is the most common failure mode. This failure mode is usually related to improper operation of the synchronous belt, low installation tension, too small diameter of the pulley and foreign matters in the pulley.
3.橡膠同步帶安裝張力低導致失效
3. Low installation tension of rubber synchronous belt leads to failure
安裝張力過低會導致同步帶在中度到高度負荷的傳動系統中過早失效。安裝張力過低的失效模式常見的表現形式為跳齒。跳齒即是同步帶的齒爬出超出其對應的輪槽范圍，并且同步帶的根部不再承受負荷。傳動負荷進一步作用于同步帶側面使同步帶齒部發生變形，隨之出現跳動。這種情況下，跳齒會導致橡膠從齒根沿著芯線撕裂，同時隨著橡膠撕裂程度的加重，同步帶齒部會開始以條狀的形式脫離同步帶。此種失效模式要于由于粘度不足導致的失效模式有所不同，粘度不足導致的失效模式，同步帶中外露芯線是較為整潔的。
Too low installation tension will cause premature failure of the timing belt in the transmission system with moderate to high load. The common failure mode of low installation tension is tooth skipping. Tooth skipping means that the teeth of the synchronous belt climb out of the range of its corresponding wheel groove, and the root of the synchronous belt will no longer bear the load. The transmission load further acts on the side of the synchronous belt, causing the tooth of the synchronous belt to deform and jump. In this case, tooth skipping will cause the rubber to tear along the core line from the tooth root. At the same time, with the aggravation of the rubber tear, the teeth of the synchronous belt will begin to separate from the synchronous belt in the form of strip. This failure mode is different from the failure mode caused by insufficient viscosity. For the failure mode caused by insufficient viscosity, the exposed core wire in the synchronous belt is relatively clean.
4.帶輪質量導致的失效
4. Failure caused by pulley quality
帶輪的生產不符合標準以及帶輪磨損情況嚴重都會導致同步帶出現過早失效，而且這兩種原因引起的失效非常難以區分。帶輪導致同步帶失效的情況很容易被忽略，因?yàn)橐话阃綆С霈F(xiàn)失效，我們會著重從同步帶本身去排查原因。由于帶輪問題導致的同步帶出現失效，一般同步帶側面是呈現模糊的絨毛狀或片狀。
The production of pulley does not meet the standard and the serious wear of pulley will lead to premature failure of synchronous belt, and the failure caused by these two reasons is very difficult to distinguish. The synchronous belt failure caused by the pulley is easy to be ignored, because the general synchronous belt fails, we will focus on the synchronous belt itself. The synchronous belt fails due to the pulley problem. Generally, the side of the synchronous belt is fuzzy fluff or flake.
5.帶輪跳動
5. Pulley runout
帶輪跳動的越厲害，張緊力就升得越高。帶輪旋轉時同步帶的張緊力會周期性的升降，當同步帶運行在徑向跳動的帶輪系統中時。受帶輪跳動的影響，齒底看起來會像是被碾碎的樣子。碾碎的帶體可能會與在適度尺寸帶輪中而運行的同步帶張緊力過高所導致的現象相類似。而極端周期性的張力變化常常導致同步帶齒部撕裂或同步帶拉伸性斷裂。帶輪往錐套上安裝，或在更小的帶輪光孔基礎上進行再擴孔后安裝時，往往容易發生跳動。
The more the pulley jumps, the higher the maximum tension rises. When the pulley rotates, the tension of the synchronous belt will rise and fall periodically. When the synchronous belt runs in the radial beating pulley system. Affected by the runout of the pulley, the tooth bottom will look like being crushed. The crushed belt body may be similar to the phenomenon caused by excessive tension of synchronous belt running in moderately sized pulley. The extreme periodic tension changes often lead to the tearing of the teeth of the synchronous belt or the tensile fracture of the synchronous belt. When the pulley is installed on the cone sleeve or after re reaming on the basis of the smallest pulley smooth hole, it is often easy to jump.
6.空氣腐蝕導致的失效
6. Failure caused by air corrosion
同步帶應用于翻砂攪拌機，鐵礦石加工設備，磷酸鹽采礦輸送設備時，容易受腐蝕性空氣的影響。由于長期在易容腐蝕空氣腐蝕的環境下使用而導致的失效，一般情況下，帶齒側面和同步帶齒底的磨損會呈現光亮狀。帶輪在易受腐蝕空氣中使用應該增加帶輪和同步帶更換的頻率，或者是采取安裝有潔凈空氣加壓的密封罩，可以有效防止腐蝕性的灰塵雜質進入裝置。
When the synchronous belt is used in sand turning mixer, iron ore processing equipment and phosphate mining conveying equipment, it is easy to be affected by corrosive air. Failure caused by long-term use in an environment prone to corrosion and air corrosion. Generally, the wear on the side of the belt teeth and the bottom of the synchronous belt teeth will appear bright. When the pulley is used in corrosive air, the replacement frequency of pulley and synchronous belt should be increased, or a sealing cover with clean air pressurization should be installed to effectively prevent corrosive dust and impurities from entering the device.
7.因高溫降解導致失效
7. Failure due to high temperature degradation
當橡膠同步帶長期于高于85℃的高溫環境下工作時，橡膠會由于高溫而硬化，在運轉過程中會容易出現背部開裂，這些開裂通常與齒的運行方向呈現平行的狀態，而且多發生在齒中間。
When the rubber synchronous belt works at a high temperature higher than 85 ℃ for a long time, the rubber will harden due to high temperature, and it is easy to have back cracks during operation. These cracks are usually parallel to the running direction of the teeth, and mostly occur in the middle of the teeth.
8.化學降解導致失效
8. Failure due to chemical degradation
橡膠同步帶在揮發性有機溶劑和臭氧的環境下與上文提及由于高溫導致的失效情況相類似。同樣是由于成分變硬然后導致同步帶背部出現開裂。但是開裂的形式有所區別，一般是呈現縱橫向的開裂，甚各種形狀的開裂均有可能。
The failure of rubber synchronous belts in the environment of volatile organic solvents and ozone is similar to that caused by high temperature mentioned above. It is also due to the hardening of the composition, which leads to the cracking of the back of the synchronous belt. However, the forms of cracking are different, generally showing vertical and horizontal cracking, and even cracking of various shapes are possible.
9.異物進入導致的失效
9. Failure caused by foreign matter entry
帶輪和橡膠同步帶之間有異物的情況會導致帶齒和芯線的損壞，通常這種情況，芯線內部狐呈現斷裂狀或者使用不久后發生過度彎曲而失效。
Foreign matters between the pulley and the rubber synchronous belt will cause damage to the belt teeth and the core wire. Generally, in this case, the internal part of the core wire is broken or becomes invalid due to excessive bending shortly after use.
