1運送機在正常工作條件下應具有滿足的穩定性和強度。
1. The conveyor should have satisfied stability and strength under normal working conditions.
2電氣裝置的規劃與裝置有必要符合GB4064和GBJ232的規定。
It is necessary for the planning and installation of electrical devices to comply with the requirements of GB4064 and GBJ23 2.
3未經規劃或制作單位同意，用戶不該進行影響運送機原規劃、制作、裝置要求的變化。
Without the consent of the planning or production unit, the user should not change the safety requirements of the original planning, production and installation of the conveyor.
4運送機有必要按物料特性與運送量要求選用，不得超載運用，有必要避免堵塞和溢料，保持運送暢通。
4. It is necessary to select the conveyor according to the material characteristics and transportation requirements. It is not allowed to be overloaded. It is necessary to avoid blockage and spills and to maintain smooth transportation.
a．運送帶應有適合特定的載荷和運送物料特性的滿足寬度；
A. The conveyor belt shall have a suitable width for specific loads and material characteristics;
b．運送機傾角有必要規劃成能避免物料在正常工作條件下打滑或滾落；
B. It is necessary to plan the inclination angle of the conveyor so as to avoid material slipping or rolling under normal working conditions.
c．運送機應設置保證均勻給料的操控裝置；
C. The conveyor should be equipped with a control device to ensure uniform feeding.
d．料斗或溜槽壁的坡度、卸料口的方位和尺寸有必要能保證物料靠自身重力自動地流出；
D. The gradient of hopper or chute wall, the direction and size of discharge port are necessary to ensure that the material flows out automatically by its own gravity.
e．受料點應設在水平段，并設置導料板。受料點有必要設在歪斜段時，需設輔佐裝料設施；
E. The receiving point should be located in the horizontal section and the guide plate should be set. When it is necessary to set up the feeding point in the skewed section, auxiliary feeding facilities should be set up.
f.筆直拉緊裝置區段應裝設落料擋板。
F. Blanking baffles shall be installed in the straight tensioning device section.
g .受料點宜采納下降沖擊力的辦法。
G. The method of reducing impact force should be adopted at the receiving point.
5、物料有粘性時運送機的滾筒表面、回程段帶面應設置相應的清掃裝置。運送帶的歪斜段尾部滾筒前好設置擋料板，這樣就可以避免運送帶跑偏。
5. When the material is sticky, the surface of the drum and the belt surface of the return section of the conveyor should be equipped with corresponding cleaning devices. It is better to set up a baffle in front of the tail drum of the deviated section of the conveyor belt, so as to avoid the deviation of the conveyor belt.
