輸送機是一種,通用的連續(xù)運輸設備,用作支撐部件,輸送力通過靜摩擦實現,當然使用期間也會出現一些問題,比如偏差方面,那么輸送帶本身使用會引起怎樣的偏差?
Conveyor is a kind of efficient, universal continuous transport equipment, used as a support component, conveying force through static friction, of course, there will be some problems during the use, such as deviation, then the use of the conveyor belt itself will cause what kind of deviation?
輸送帶本身的芯層中間,特別是鋼絲繩芯輸送帶的中間力不均勻,雙向鋼絲繩的不均勻力不可避免地導致輸送帶的偏斜。輸送帶不規(guī)范,制成蛇形會引起偏差。輸送帶接頭的質量保證應保證其抗拉強度。相反,應確保接頭的切割邊緣垂直于傳送帶的線,以使接頭后的環(huán)形帶長度改變,否則會導致傳送帶偏離。
In the middle of the core layer of the conveyor belt itself, especially the middle force of the steel wire rope core conveyor belt is not uniform. The uneven force of the two-way steel wire rope inevitably leads to the deflection of the conveyor belt. Conveyor belt is not standard, made into a snake will cause deviation. The quality assurance of the conveyor belt joint shall ensure its tensile strength. Instead, ensure that the cut edge of the joint is perpendicular to the centerline of the conveyor belt so that the length of the ring behind the joint changes, otherwise the conveyor belt will deviate.

安裝引起的偏差也不能忽略,比如頭和尾輥螺絲不垂直于輸送機的初始線,這會導致輸送帶的雙向張力有所不同。滾筒支架不垂直于輸送機的初始線。帶槽托輥組的軸向傾斜輥的槽角不相等。滾筒支架的安裝傾斜,從而使輸送機的滾筒支架不在同一水平線上,從而導致輸送帶上的物料未對準并導致傳送帶偏離。
Deviations caused by installation can not be ignored, such as head and tail roller screws are not perpendicular to the initial center line of the conveyor, which will lead to different bidirectional tension of the conveyor belt. The drum support is not perpendicular to the initial center line of the conveyor. The grooves of the axial tilting rollers with grooves are not equal. The installation of roller bracket is tilted, so that the roller bracket of the conveyor is not on the same level, which leads to the material on the conveyor belt is not aligned and leads to the deviation of the conveyor belt.
山東輸送帶廠家提醒大家,環(huán)境造成的偏差同樣要多注意,安裝在露天的輸送機,尤其是越野長途皮帶輸送機,會受到天氣變化的影響,例如風,雨和雪,這也會導致輸送帶偏離。
Shandong conveyor belt manufacturers remind you that the deviation caused by the environment should also pay more attention to the installation of the conveyor in the open air, especially the cross-country long-distance belt conveyor, will be affected by weather changes, such as wind, rain and snow, which will also lead to conveyor belt deviation.
輸送帶出現偏差還是比較常見的故障,這導致設備的輸送效率降低,應盡可能避免這一問題的出現。更多問題的詳情您可以來網站
www.ujkdbkh.cn看看資訊!
Conveyor belt deviation is still a common fault, which leads to the reduction of the transmission efficiency of equipment, and this problem should be avoided as far as possible. For more information about the problem, please visit www.ujkdbkh.cn!
