裙邊輸送帶可在環境溫度-20℃+40℃范圍內使用,被送物料溫度小于60℃。
The skirt conveyor belt can be used in the range of ambient temperature - 20 ℃ to + 40 ℃, and the temperature of the delivered material is less than 60 ℃.
所以輸送帶在使用中應該注意以下事項:
Therefore, the conveyor belt in use should pay attention to the following matters:
(1) 避免托輥被物料覆蓋,造成回轉不靈,防止漏料卡于滾筒與膠帶之間,注意活動部分的潤滑,但不得油污輸送帶;
(1) Avoid the idlers being covered by materials, resulting in poor rotation, to prevent leakage stuck between the drum and the belt, pay attention to the lubrication of the moving part, but do not oil the conveyor belt;
(2)避免帶負荷啟動;
(2) Avoid starting with load;
(3)膠帶發生跑偏,應該及時采取措施糾正;
(3) The belt deviation should be corrected in time;
(4)發現膠帶局部操作應該及時修補,以免擴大;
(4) If it is found that the local operation of the adhesive tape should be repaired in time to avoid expansion;
(5)避免膠帶遭受機架,支柱或塊狀物料的阻滯,防止碰破扯裂。
(5) Avoid the block of the belt by the frame, pillar or block material to prevent the belt from cracking.
1、 輸送帶在運輸和貯存中,應保持清潔避免陽光直射或者雨雪浸淋,防止與酸堿油類有機溶劑等物質接觸,并距離發熱源少一米;

1. During transportation and storage, the conveyor belt should be kept clean, avoid direct sunlight or rain and snow, avoid contact with acid, alkali, oil, organic solvents and other substances, and be at least one meter away from the heat source;
2、 貯存時倉庫內溫度宜保持在-18℃-40℃之間,相對溫度宜保持在50%-80%之間;
2. During storage, the temperature in the warehouse should be kept between - 18 ℃ and 40 ℃, and the relative temperature should be kept between 50% and 80%;
3、 貯存期間,產品須成卷放置,不得折疊,放置期間應每季翻動一次;
3. During storage, the products should be placed in rolls and not folded. During storage, they should be turned over once a quarter;
4、 不同類型、規格層數的輸送帶不宜接在一起,其接頭較好采用膠接法;
4. The conveyor belts with different types, specifications and layers are not suitable to be connected together, and the bonding method is better;
5、 輸送帶的類型、結構、規格、層數應根據使用條件合理選用。
5. The type, structure, specification and number of layers of conveyor belt should be selected reasonably according to the service conditions.
6、 輸送膠帶運行速度一般不宜大于2.5米/秒,塊度大,磨損性大的物料和使用固定類型卸料裝置應盡量采用低速;
6. Generally, the running speed of conveyor belt should not be greater than 2.5 m / s. low speed should be used for materials with large block size and wear resistance and fixed discharge device;
7、 運輸機的傳動滾筒直徑與輸送帶布層的關系,傳動滾筒,改向滾筒的配套以及對托輥槽角的要求應根據運輸機的設計規定,合理選??;
7. The relationship between the diameter of the driving roller and the cloth layer of the conveyor belt, the matching of the driving roller and the steering roller, and the requirements for the groove angle of the idler should be reasonably selected according to the design regulations of the conveyor;
8、 給料方向應順膠帶的運行方向,為減小物料下落時對膠帶的沖擊應采用溜槽,減少物料下落距離;膠帶受料段應縮短托輥間距和采用緩沖托輥,為防止漏料,帶側應采用柔軟適度的擋料板,以免擋料板過硬,刮破輸送帶的帶面。
8. The feeding direction should be along the running direction of the belt. In order to reduce the impact of falling materials on the belt, chute should be used to reduce the falling distance of materials; The distance between rollers should be shortened and buffer rollers should be used in the receiving section of the belt. In order to prevent material leakage, a soft and moderate baffle plate should be used at the belt side, so as not to scratch the belt surface of the conveyor belt.
