1. The conveyor belt is connected by the belt buckle, and the joint can only reach about 70% of the rated tensile strength of the belt body, which is easy to cause fracture at the joint;

2．輸送帶接頭直接通過輸送帶扣連接，輸送帶扣與帶體垂直布置，受力更加集中，長時間在高強度拉力的工作條件下， 輸送帶扣與帶面容易出現拔脫，造成斷帶；

2. The conveyor belt joint is directly connected through the conveyor belt buckle, and the conveyor belt buckle is vertically arranged with the belt body, so the force is more concentrated. Under the working condition of high tensile force for a long time, the conveyor belt buckle and the belt surface are easy to pull out, resulting in broken belt;

3．輸送帶扣與帶體垂直布置，由于輸送帶中間的托輥承載70%的物料重量，兩側托輥各承載15%，這樣輸送帶扣與各個滾筒托輥直線撞擊擦過，導致輸送帶扣中間部分磨損嚴重；

3. The belt buckle is vertically arranged with the belt body. As the idler in the middle of the belt carries 70% of the material weight, and the idler on both sides carries 15% of the material weight respectively, the belt buckle and the idler of each drum collide and rub in a straight line, resulting in serious wear of the middle part of the belt buckle;

4．輸送帶主要采用的刮板式清掃器安裝在卸載滾筒的下方，清掃器的刮板與輸送帶扣直線撞擊過去，導致輸送帶扣和清掃器刮板磨損嚴重。

4. The scraper sweeper mainly used in the conveyor belt is installed under the unloading roller, and the scraper of the sweeper and the conveyor belt buckle collide in a straight line, resulting in serious wear of the conveyor belt buckle and the scraper of the sweeper.

織物輸送帶用帶扣斜式連接結構，屬于織物輸送帶連接扣技術領域， 是一種采用傾斜結構布置，能夠有效增加輸送帶額定拉伸強度，減少受力集中，避免斷帶，降低輸送帶扣的磨損?？椢镙斔蛶в脦Э坌笔竭B接結構，所采用的技術方案為織物輸送帶通過織物輸送帶扣連接，織物輸送帶扣之間貫穿有串條， 織物輸送帶的接頭端為斜邊，斜邊與織物輸送帶帶邊的夾角為45°，沿織物輸送帶的接頭端依次釘上斜式輸送帶扣，本技術廣泛用于織物輸送帶的接頭連接。

The oblique connection structure of belt buckle for fabric conveyor belt belongs to the technical field of fabric conveyor belt connection buckle. It is a kind of inclined structure arrangement, which can effectively increase the rated tensile strength of conveyor belt, reduce the stress concentration, avoid belt breakage and reduce the wear of conveyor belt buckle. The technical scheme adopted is that the fabric conveyor belt is connected through the fabric conveyor belt buckle, and a string of strips are penetrated between the fabric conveyor belt buckles, The joint end of the fabric conveyor belt is beveled edge, and the included angle between the beveled edge and the edge of the fabric conveyor belt is 45 degrees. The inclined conveyor belt buckle is nailed along the joint end of the fabric conveyor belt in turn. This technology is widely used in the joint connection of the fabric conveyor belt.

1．織物輸送帶用帶扣斜式連接結構，包括織物輸送帶，織物輸送帶通過輸送帶扣連接，輸送帶扣之間貫穿有串條，織物輸送帶的接頭端為斜邊，斜邊與織物輸送帶帶邊的夾角為45°，沿織物輸送帶的接頭端依次釘上斜式輸送帶扣。

1. The fabric conveyor belt uses belt buckle inclined connection structure, including fabric conveyor belt. The fabric conveyor belt is connected by belt buckle, and there are string bars between belt buckles. The joint end of fabric conveyor belt is beveled edge, and the included angle between beveled edge and belt edge of fabric conveyor belt is 45 degrees. The beveled belt buckle is successively nailed along the joint end of fabric conveyor belt.
