How to reduce the damage to conveyor belt caused by different positions? There will be a conveyor manufacturer's staff below to introduce them to you

　　一、調速滾桶與輸送帶損壞：反轉滾桶坐落于皮帶輸送機尾端，輸送帶隨反轉滾桶一起轉動，使下輸送帶變成上輸送帶開展原材料運輸。

　　1、 Speed control barrel and conveyor belt are damaged: the reverse barrel is located at the end of the belt conveyor, and the conveyor belt rotates with the reverse barrel, so that the lower conveyor belt becomes the upper conveyor belt for raw material transportation.

　　1、在調速鼓表層周邊安裝刮板板。刮料板與刮料板總體電焊焊接。刮料板用地腳螺栓固定不動在輸送架上，刮料板與滾桶歪斜一定視角，以提升刮料工作能力。

　　1. Install scraper around the surface of speed regulating drum. The scraping plate and the scraping plate are welded by electric welding. The scraper plate is fixed on the conveying frame with the anchor bolt, and the scraper plate and the barrel are tilted at a certain angle to improve the scraping capacity.

　　2、在反轉鼓前側安裝V型給礦機（用地腳螺栓與聲卡機架聯接），給礦機與輸送帶觸碰端安裝硫化橡膠條，降低傳動帶損壞。

　　2. V-type feeder is installed at the front side of the reverse drum (connected with the sound card rack by the anchor bolt), and vulcanized rubber strip is installed at the contact end of the feeder and the conveyor belt to reduce the damage of the drive belt.

　　3、除此之外，為處理反轉鼓前無支撐點段溢料的難題，也可在無支撐點段安裝隔板，以降低溢料。

　　3. In addition, in order to deal with the problem of overflow in the unsupported section before the reverse drum, a baffle plate can also be installed in the unsupported section to reduce the overflow.

　　二、傳動帶方向跑偏導致的部分損壞：輸送帶方向跑偏是輸送帶常見問題，主要是輸送帶運作時，輸送帶軸線偏移輸送帶豎向軸線。能夠采用維護保養對策

　　2、 Partial damage caused by the direction deviation of the transmission belt: the direction deviation of the conveyor belt is a common problem of the conveyor belt, mainly because the axis of the conveyor belt deviates from the vertical axis of the conveyor belt during the operation of the conveyor belt. Able to adopt Maintenance Countermeasures

　　1、首尾鼓不平行面，出現跑緊跑不軟狀況假如全部皮帶輸送機的軸線有誤差，則必須再次校正軸線；假如只能輕度誤差，則能夠扭緊帶座軸承。但這類方式 只有調節較小的偏移。針對很大的偏移，可將尾鼓安裝在挪動小轎車上（見下面的圖），并可調節小轎車以改正誤差。

　　1. The uneven running surface of the head and tail drum, in case of tight running and soft running, if the axis of all belt conveyors has errors, the axis must be corrected again; if only slight errors can be made, the bearing of the belt seat can be tightened. But this kind of way only adjusts the small offset. For a large offset, the tail drum can be installed on the mobile car (see the figure below), and the car can be adjusted to correct the error.

　　2、因為輸送帶自身彎折彎曲或連接頭有誤，造成輸送帶負荷不勻稱，導致方向跑偏。輸送帶應激光切割、再次黏合或釘牢。

　　2. Because the conveyor belt itself is bent or the connector is wrong, the load of the conveyor belt is uneven, resulting in the direction deviation. The conveyor belt shall be laser cut, re bonded or nailed.

　　3、緩沖托輥組線與輸送帶軸線不豎直，導致輸送帶運作后不往前運作，即輸送帶向后運作（與輸送帶方位反過來）。假如調節方式 是偏移哪一側，則哪一側的緩沖托輥將偏移輸送帶正確方向24度，一般狀況下，應調節好多個緩沖托輥以改正誤差。

　　3. The central line of the buffer idler group is not vertical to the axis of the conveyor belt, resulting in the conveyor belt does not move forward after operation, that is, the conveyor belt operates backward (opposite to the direction of the conveyor belt). If the adjustment method is to offset which side, the buffer idler on which side will offset the correct direction of the conveyor belt by 2 to 4 degrees. In general, many buffer idlers should be adjusted to correct the error.

　　三、惰輪和輸送帶中間的損壞：能夠采用維護保養對策

　　3、 Damage between idler and conveyor belt: able to adopt maintenance measures

　　1、，保證全部皮帶輸送機處在軸線上；次之，兩邊歪斜緩沖托輥與正中間水準緩沖托輥具備同樣的歪斜視角。全部正中間緩沖托輥均在同一水準表面，使全部緩沖托輥與輸送帶觸碰優良，以確保各緩沖托輥支承勻稱。

　　1. First of all, ensure that all the belt conveyors are on the axis; second, the skew buffer idlers on both sides and the level buffer idlers in the middle have the same skew angle of view. All the intermediate buffer idlers are on the same level surface, so that all the buffer idlers touch the conveyor belt well, so as to ensure the uniform support of each buffer idlers.

　　2、盡量避免應用調心輥。

　　2. Try to avoid the application of the centering roller.

　　3、提升緩沖托輥的平時維護保養，立即拆換毀壞的緩沖托輥。

　　3. Lift the buffer idler for routine maintenance, and immediately replace the damaged buffer idler.
